Core Facility Electron Microscopy and Scanning Probe Methods
For the user policy and usage fees for electron microscopes and FIB instruments, please visit the following link:
Transmission Electron Microscopes
mar.quest is equipped with a variety of (scanning) transmission electron microscopes (TEM/STEM) featuring diverse configurations and specializations. These instruments enable the investigation of a wide range of research questions—from biological samples under cryogenic conditions to high-resolution imaging and spectroscopy, as well as in-situ experiments in gas atmospheres.
Further details on the specifications of individual microscopes can be found by clicking on their respective names."
| Microscope | Location | Person Responsible (Details s.b.) |
| Scanning-TEM JEOL NEOARM JEM-ARM200F (ATEMMA) | LB, mar.quest | AB, KV |
| Scanning-TEM JEOL JEM-2200FS | LB, mar.quest | AB, KV |
| JEOL JEM-Z200FSC (CRYO ARM™ 200) | LB, Synmikro | GB |
| TEM JEOL 2100 | LB, FB Biology | TH |
| TEM JEOL JEM-3010 |
LB, mar.quest | MH, AB, KV |
| TEM Hitachi HU 12 | LB, FB Biology | HKH |
| TEM Zeiss 109 | RKS, Zytobiology | HPE |
Scanning Electron Microscopes / Focused Ion Beam Systems
In addition to transmission electron microscopes (TEM), mar.quest's infrastructure includes multiple scanning electron microscopes (SEM) and focused ion beam (FIB) systems. When combined with analytical techniques such as EDX and EBSD, these instruments enable comprehensive material characterization as well as precise sample preparation for TEM analysis.
For detailed information on the instrumentation of the systems, please click on the respective instrument name.
| Microscope | Location | Person Resposible (Details s.b.) |
| PFIB-SEM Helios 5 Hydra CX (Thermofisher Scientific/FEI) |
LB, mar.quest | CB |
| FIB-SEM JEOL JIB-4601F |
LB, mar.quest | CB |
| FIB-SEM Zeiss Crossbeam 550 | LB, mar.quest | FN, PK |
| SEM Hitachi S-530 | LB, FB Biology | KHR |
| SEM Hitachi S-4100 | LB, mar.quest | CB, KV |
Sample Preparation for Electron Microscopy
mar.quest offers diverse tools for electron microscopy sample preparation, supporting both biomedical and materials science research.
Biomedical Research
| Tool |
Location |
Person Responsible (Details s.b.) |
| High Pressure Freezer (Wohlwend Compact 02) | LB, FB Biology | TH |
| Plunge Freezer (self-made) | LB, FB Biology | TH |
| Freeze-Substitution System (Leica AFS2) | LB, FB Biology | TH |
| Cryo-Etching System (Balzers BAF301) | LB, FB Biology | TH |
| Vapor Deposition System (Balzers BAE121) | LB, FB Biology | TH |
| Sputter System (Gold) (Technics Hummer I) | LB, FB Biology | TH |
| Glow Discharger (PELCO easiGlow) | LB, FB Biology | TH |
| Turbopumping Station (Gatan Model 655) | LB, FB Biology | TH |
| Ultramicrotome (Leica EM UC7 RT) | LB, FB Biology | TH |
| Ultramicrotome (Reichert-Jung Ultracut) | LB, FB Biology | TH |
| Knifemaker (LKB 7801B) | LB, FB Biology | TH |
| Cryo-Ultramicrotome (Leica ULTRACUT UCT/FCS) | LB, mar.quest | MH |
| Critical-Point Dryer (VG Microtech) | LB, mar.quest | MH |
| Sputter-Coater (Leica ACE 600) | LB, mar.quest | MH |
| Ultramicrotome (Reichert-Jung Ultracut E) | RKS, Zytobiology | HPE |
| Ultramicrotome (Reichert-Jung Ultracut FC4E) | RKS, Zytobiology | HPE |
Material Sciences
| Tool |
Location |
Person Responsible (Details s.b.) |
| Ion Milling System PIPS (Gatan) | LB, mar.quest | CB |
| 2 Diamond Wire Saws (Well, Model 3242 & 3500) | LB, mar.quest | MH |
| Ultrasonic Core Cutter (Gatan, USA) | LB, mar.quest | MH |
| Dimpler (Fischione) | LB, mar.quest | CB |
| Fischione Model 1020 Plasmacleaner | LB, mar.quest | CB |
| Tergeo Plasmacleaner | LB, mar.quest | CB |
| Fischione Model 1040 Nanomill | LB, mar.quest | CB |
Contact Details
| Name | Contact Information |
| Prof. Dr. G. Bange GB |
Tel.: 06421 / 28-23361 E-Mail: gert.bange@synmikro |
| C. Becker CB |
Tel.: 06421 / 28-22260 E-Mail: celina.becker@physik |
| Dr. A. Beyer AB |
Tel.: 06421 / 28-25704 E-Mail: andreas.beyer@physik |
| Prof. Dr. H. P. Elsässer HPE |
Tel.: 06421 / 28-64075 E-Mail: elsaesse@staff |
| Dr. T. Heimerl TH |
Tel.: 06421 / 28-21509 E-Mail: thomas.heimerl@synmikro |
| M. Hellwig MH |
Tel.: 06421 / 28-23458 E-Mail: michael.hellwig@staff |
| P. Kahler PK |
Tel.: 06421 / 28-25789 E-Mail: philipp.kahler@chemie |
| H. Kisselbach-Heckmann HKH |
Tel.: 06421 / 28-23378 E-Mail: kisselba@biologie |
| F. Noll FN |
Tel.: 06421 / 28-25424 E-Mail: noll@staff |
| Dr. K.-H. Rexer KHR |
Tel.: 06421 / 28-25436 E-Mail: rexer@biologie |
| Prof. Dr. K. Volz KV |
Tel.: 06421 / 28-22297 E-Mail: kerstin.volz@physik |
For a complete E-mail address, please add ".uni-marburg.de".
